NC3FXX-HD-D

NC3MXX-HD-D

NC3FX

NC3MX + BSX-5

NC*FX

NC*MX

NC3MXX-HD-B-D

innovative

solutions

I superior quality

XLR

Cable

Connectors

XLR

Cable

Connectors

XX-HD Series

Rubber sealing

protection

Neutrik original

design

• The XLR connector standard worldwide

• Available in 3 - 7 pin configurations including 6 pin

Switchcraft® configuration

• Assembly is quick and easy – no screws or special tools

required

• Unique Neutrik chuck type internal strain relief

• Female shell has rubber ring for secure mating to male XLR

or microphone

• Sleek profile and compact design

• Rugged diecast shell

• UL Recognized components

• "Heavy duty" cable connector for outdoor use

• Rubber sealing jacket protects against water ingress and

mechanical shock

• Dust and water resistant according IP 67 in mated condition

• NC3FXX-HD mates with NC3MPR-HD chassis connector

and NC3MXX-HD cable connector

• Gold contacts

• Chuck type strain relief system for secure clamping of cables

• Rugged zinc diecast shell, longlasting and dependable

*: 3 - 7 contacts

X Series

Female locking

Male metal locking

window
