TECHNICAL DATA SHEET

50 Ohm TNC DC Block Operating From 10 MHz to 18 GHz

Configuration

Design

Outer DC Block

Body Style

Straight

Impedance

50 Ohms

Connector 1

TNC Male

Connector 2

TNC Female

Electrical Specifications

Frequency Range, GHz

0.01 to 18

Impedance, Ohms

50

Maximum VSWR

1.35:1

Maximum Insertion Loss, dB

0.75

Maximum Operating Voltage, Vrms

200

Mechanical Specifications

Size

Length, in [mm]

2.11 [53.59]

Width/Dia., in [mm]

0.59 [14.99]

.

Connector 1

Type

TNC Male

Dielectric Type

PTFE

Inner Conductor Material and Plating

Gold

Coupling Nut Material and Plating

Brass, Nickel

Body Material and Plating

Passivated Stainless Steel

Connector 2

Type

TNC Female

Dielectric Type

PTFE

Inner Conductor Material and Plating

Gold

Body Material and Plating

Passivated Stainless Steel

RoHS Compliant

Yes

Click the following link (or enter part number in “SEARCH” on website) to obtain additional part information including price,

inventory and certifications: 50 Ohm TNC DC Block Operating From 10 MHz to 18 GHz PE8220

PE8220

PE8220 REV

50 Ohm TNC DC Block Operating From 10 MHz to 18 GHz
