UL75

Preliminary

CMOS IC

UNISONICTECHNOLOGIESCO.,LTD

4 of 7

www.unisonic.com.tw

QW-R125-051.b



ABSOLUTE MAXIMUM RATING

PARAMETER

SYMBOL

RATINGS

UNIT

Input Voltage

-0.3 ~ 550

V

Supply Voltage

-0.3 ~ 10

V

Output Current, Source Or Sink

0 ~ 200

mA

ST Input Voltage

-0.3 ~ 15

V

3000

mW

Junction Temperature

-55 ~ +125

°C

Storage Temperature

-55 ~ +150

°C

Note: Absolute maximum ratings are those values beyond which the device could be permanently damaged.

Absolute maximum ratings are stress ratings only and functional device operation is not implied.



RECOMMENDED OPERATING CONDITIONS (Note)

PARAMETER

SYMBOL

RATINGS

UNIT

Input Voltage

140 ~ 375

V

Supply Voltage

5.5 ~ 6.5

V

Sink/Source Load Current (steadystate)

0 ~ 100

mA

Sink/Source Load Current (peak)

0 ~ 200

mA

Reference Load Current

0 ~ 100

mA

ST Input Voltage

0 ~ 7

V

Operating Ambient Temperature

0 ~ +70

°C

Note: Range over which the device is functional and parameter limits are guaranteed.



THERMAL DATA

PARAMETER

SYMBOL

RATINGS

UNIT

Junction to Case

50

°C/W

Note: Thermal resistance junction-alumina with the device soldered on the middle of an alumina supporting

substrate measuring 15×20mm; 0.65mm thickness with infinite heat sink.
