ELECTRICAL CHARACTERISTICS (TEMPER=25°C, unless otherwisespecified)
PARAMETER
SYMBOL
TEST CONDITIONS
MIN
TYP
MAX
UNIT
POWER SECTION
Input Voltage
VIN
0
220
500
V
Output Led Current
ILED
VIN=110AC, 220AC
0
50
130
mA
Supply Voltage
VDD
5.5
6
6.5
V
Power Efficiency
η
ILED=100mA
0.7
0.8
0.9
Power Factor
PF
ILED=100mA
0.7
0.9
0.96
CC SECTION
The Precision Of Constant
Current
CC
ILED=50mA~100mA
±5
%
RSET Pin Voltage
VSET
0.594
0.6
0.606
V
Standby Power Consumption
15
25
mW
PROTECTION SECTION
Short Circuit Protection Current
ILED_st
VIN=220AC
120
130
140
mA
Input Voltage Protection
VIN_OV
RST=20.5MΩ
245
265
285
V
LED Limit Current Protection
ILED_LIM
VIN=220AC
120
130
140
mA
LDMOS SECTION
LDMOS Withstand Voltage
BV
500
550
600
V
ION_S1
71
mA
ION_S2
85
mA
LDMOS Current
ION_S3
100
mA
TEMPER SETION
Over Temper Protection
TOTP
145
°C
Over Temper Hysteresis
THYS
20
°C
Note: The parameters are not 100% tested in production.
