STM32U535xx

Functional overview

–

Data alignment with built-in data coherency

–

DMA support

•

Low-power

–

HCLK frequency reduced for low-power operation while still keeping optimum

ADC performance

–

Wait mode: ADC overrun prevented in applications with low frequency HCLK

–

Auto-off mode: ADC automatically powered off except during the active

conversion phase, dramatically reducing the ADC power consumption

–

Autonomous mode: In low-power modes down to Stop 2 mode, the ADC4 is

automatically switched on when a trigger occurs to start conversion, and it is

automatically switched off after conversion. Data are transfered in SRAM

with DMA.

–

ADC4 interrupts wake up the device from Stop 0, Stop 1 and Stop 2 modes.

•

Analog input channels

–

Up to 19 external analog inputs

–

One channel for the internal temperature sensor (VSENSE)

–

One channel for the internal reference voltage (VREFINT)

–

One channel for the internal digital core voltage (VCORE)

–

One channel for monitoring the external VBAT power supply pin

–

Connection to two DAC internal channels

•

Start-of-conversion can be initiated:

–

By software

–

By hardware triggers with configurable polarity (timer events or GPIO input

events)

•

Conversion modes

–

Conversion of a single channel or scan of a sequence of channels

–

Selected inputs converted once per trigger in Single mode

–

Selected inputs converted continuously in Continuous mode

–

Discontinuous mode

•

Interrupt generation at the end of sampling, end of conversion, end of sequence

conversion, and in case of analog watchdog or overrun events, with wake-up from Stop

capability

•

Analog watchdog

•

Oversampler

–

16-bit data register

–

Oversampling ratio adjustable from 2 to 256

–

Programmable data shift up to 8 bits

•

ADC supply requirements: 1.62 to 3.6 V

•

ADC input range: VSSA < VIN < VREF+

Note:

The ADC4 analog block clock frequency must be between 140 kHz and 55 MHz.
