background image
3.General Specifications
 Size: 15.0 inch
 Dot Matrix: 1024 x RGB x 768 (TFT) dots
 Module dimension: 326.5 x 253.5 x9.1 mm
 Active area: 304.1 x 228.1 mm
 Dot pitch: 0.297 x 0.297 mm
 LCD type: TFT, Normally Black, Transmissive
 Viewing Angle: 88/88/88/88
 Backlight Type: LED,Normally White
 Interface: LVDS
 With /Without TP: Without TP
 Surface: Anti-Glare
*Color tone slight changed by temperature and driving voltage.
Page 4 of 21
