background image
4.2. BACKLIGHT UNIT(Converter connector pin)
Pin
Symbol
Description
Remark
1
Vi
Converter input voltage
12V
2
VGND
Converter ground
Ground
3
EN
Enable pin
3.3V
4
Dimming
Backlight Adjust
PWM Dimming
(Hi: 3.3VDC, Lo: 0VDC)
5
NC
Not Connect
Note (1) Connector Part No.: CI4205-M2HRP-NH (Cvilux) or equivalent.
Note (2) User’s connector Part No.: H208K-D05N-22B (Entery) or equivalent
Page 6 of 21
