Notice for Automotive

Conformal coating of the component is acceptable.

However, the resin material, curing temperature, and

other process conditions should be evaluated to confirm

stable electrical characteristics are maintained.

3. Coating

Continued from the preceding page.

5 minutes max. by air blow at +80°C max.

(4) Drying

(a) Total washing time should be within 10 minutes.

(b) The component may be damaged if it is washed with

chlorine, petroleum, or alkali cleaning solvent.

(5) Other

(a) Ultrasonic Wash

1 minute max. in above solvent at +60°C max.

(Frequency: 28kHz, Output: 20W/l)

(b) Immersion Wash

5 minutes max. in above solvent at +60°C max.

(c) Shower or Rinse Wash

5 minutes max. in above solvent at +60°C max.

(3) Conditions

P16E.pdf

Nov.22,2012

15

• This catalog has only typical specifications. Therefore, please approve our product specifications or transact the approval sheet for product specifications before ordering.
