AD8436ACPZ-R7 Datasheet(PDF) 9 Page - Analog Devices |
|
|
|||||||||||||||||||||||||||||
AD8436ACPZ-R7 Datasheet(HTML) 9 Page - Analog Devices |
|
|
9 / 24 page  Data Sheet AD8436 Rev. B | Page 9 of 24 TEST CIRCUITS PRECISION DMM SIGNAL SOURCE OUT RMS +5V 10µF AC-IN MONITOR PRECISION DMM 4.7µF VEE CAV VCC 100kΩ 100kΩ 16kΩ OGND –5V IGND RMS CORE Figure 21. Core Response Test Circuit Using Dual Supplies PRECISION DMM SIGNAL SOURCE OUT RMS 4.80V 10µF AC-IN MONITOR PRECISION DMM 4.7µF 4.7µF VEE CAV VCC 100kΩ 100kΩ 16kΩ OGND IGND RMS CORE Figure 22. Core Response Test Circuit Using a Single Supply FUNCTION GENERATOR PRECISION DMM OUT RMS +5V 10µF AC-IN MONITOR PRECISION DMM 4.7µF VEE CAV VCC 100kΩ 100kΩ 16kΩ OGND –5V IGND RMS CORE Figure 23. Crest Factor Test Circuit |
|
|
