AD629
Rev. B | Page 5 of 16
TYPICAL PERFORMANCE CHARACTERISTICS
TA = 25°C, VS = ±15 V, unless otherwise noted.
FREQUENCY (Hz)
100
90
80
70
60
50
40
30
20
10
0
100
1k
10k
100k
1M
10M
Figure 5. Common-Mode Rejection Ratio vs. Frequency
VOUT (V)
–20
–16
–8
–4
0
4
8
12
16
–12
20
RL = 10kΩ
VS = ±18V
VS = ±15V
VS = ±12V
VS = ±10V
2mV/DIV
4V/DIV
Figure 6. Typical Gain Error Normalized @ VOUT = 0 V and Output Voltage
Operating Range vs. Supply Voltage, RL = 10 kΩ (Curves Offset for Clarity)
VOUT (V)
–20
–16
–8
–4
0
4
8
12
16
–12
20
RL = 1kΩ
VS = ±18V
VS = ±15V
VS = ±12V
VS = ±10V
4V/DIV
Figure 7. Typical Gain Error Normalized @ VOUT = 0 V and Output Voltage
Operating Range vs. Supply Voltage, RL = 1 kΩ (Curves Offset for Clarity)
POWER SUPPLY VOLTAGE (±V)
400
360
320
280
240
200
160
120
80
40
0
02
6
10
4
8
12
14
18
16
20
TA = +25°C
TA = +85°C
TA = –40°C
Figure 8. Common-Mode Operating Range vs. Power Supply Voltage
VOUT (V)
–20
–16
–8
–4
0
4
8
12
16
–12
20
RL = 2kΩ
VS = ±18V
VS = ±15V
VS = ±12V
VS = ±10V
4V/DIV
Figure 9. Typical Gain Error Normalized @ VOUT = 0 V and Output Voltage
Operating Range vs. Supply Voltage, RL = 2 kΩ (Curves Offset for Clarity)
VOUT (V)
–20
–16
–8
–4
0
4
8
12
16
–12
20
VS = ±5V, RL = 2kΩ
VS = ±5V, RL = 1kΩ
VS = ±2.5V, RL = 1kΩ
1V/DIV
VS = ±5V, RL = 10kΩ
Figure 10. Typical Gain Error Normalized @ VOUT = 0 V and Output Voltage
Operating Range vs. Supply Voltage (Curves Offset for Clarity)
