AP7201
DUAL 150mA LOW DROPOUT LINEAR REGULATOR
AP7201 Rev. 3
9 of 13
MAY 2014
www.diodes.com
© Diodes Incorporated
DISCONTINUED
Typical Performance Characteristics (Continued)
Output Load Transient Response
(Vout=2.8V)
Time (40us/div)
Output Load Transient Response
(Vout=3.0V)
Time (40us/div)
Output Load Transient Response
(Vout=3.3V)
Time (40us/div)
Tf=Tr=5us
Cout=1uF (ceramic)
Tf=Tr=5us
Cout=1uF (ceramic)
Tf=Tr=5us
Cout=1uF (ceramic)
Vout
50mV/div
Iout
100mA/div
Vout
50mV/div
Iout
100mA/div
Vout
100mV/div
Iout
50mA/div
