AP7201

DUAL 150mA LOW DROPOUT LINEAR REGULATOR

AP7201 Rev. 2

1 of 13

APRIL 2008

www.diodes.com

DISCONTINUED

•

Wide input voltage range: 1.9V – 5.5V

•

Low dropout voltage: 100mV at 100mA output current

•

Very low quiescent current (Iq): 25uA typical

•

Fixed output voltage: 1.0V to 3.3V

•

Up to 150mA per output channel

•

Very fast transient response

•

High PSRR: 78dB at 1kHz

•

Accurate voltage regulation

•

300mA current limiting

•

Thermal shutdown protection

•

Ambient temperature range -40ºC to 85°C

•

Package available: DFN2018-6 (USP-6B)

•

DFN2018-6 (USP-6B): Available in “Green” Molding

Compound (No Br, Sb)

•

Lead Free Finish / RoHS Compliant (Note 1)

The AP7201 is a dual low-dropout (LDO) CMOS linear regulator.

The device operates from 1.9V to 5.5V input and delivers up to

150mA per output channel.

The AP7201 includes a pass element, voltage reference, error

amplifier, current limit and built-in phase compensation. Key

features include individual logic-compatible enable/shutdown

control inputs, fold-back current limit and thermal shutdown

protections.

The AP7201 is fully compatible with low ESR ceramic capacitors,

reducing cost and improving output stability. The fixed output

voltage for each channel is set independently. Voltages are

100mV per step within a range of 1.0V to 3.3V.

The EN function allows the output of each channel to be turned

off

independently,

resulting

in

greatly

reduced

power

consumption. The AP7201 is available in the DFN2018-6

(USP-6B) package.

•

Cell Phones

•

Smart Phones and PDA

•

MP3/MP4

•

PMP

•

Bluetooth Headsets

•

Digital Still Cameras

•

GPS

AP 7201-

XX X X

Package

FM : DFN2018-6

(USP-6B)

G : Green

- 7 : Taping& Reel

XX

Lead Free

Packing

10: 1.0V

11: 1.1V

33: 3.3V

XX

Output 2

Output 1

10: 1.0V

11: 1.1V

Device

Pb-Free or

Green

Package

Code

Packaging

(Note 3)

7” Tape and Reel

Quantity

Part Number

Suffix

AP7201-1818FMG-7

FM

DFN2018-6 (USP-6B)

3000/Tape & Reel

-7

AP7201-1828FMG-7

FM

DFN2018-6 (USP-6B)

3000/Tape & Reel

-7

AP7201-2828FMG-7

FM

DFN2018-6 (USP-6B)

3000/Tape & Reel

-7

Notes:

1. RoHS revision 13.2.2003. Glass and high temperature solder exemptions applied, see EU Directive Annex Notes 5 and 7.

2. Diodes, Inc. offers custom laser trimming for additional Fixed output voltage combinations from 1.0V to 3.3V. For output voltage availability,

please contact your local Diodes, Inc. sales representative.

3. Pad layout as shown on Diodes Inc. suggested pad layout document AP02001, which can be found on our website at

http://www.diodes.com/datasheets/ap02001.pdf.

Features

General Description

Applications

Ordering Information
