AD823A

Data Sheet

Rev. | Page 12 of 20

200µs/DIV

500mV/DIV

0.5

1.0

1.5

2.0

2.5

3.0

3.5

4.0

4.5

5.0

VS = 5V

G = –1

RF = RG = 2kΩ

RL = 300Ω

CL = 50pF

Figure 31. Output Swing, +VS = +5 V, G = −1

VS = ±15V

G = +1

VOUT = 20V p-p

RL = 604Ω

CL = 50pF

10V

–10V

20µs/DIV

5V/DIV

Figure 32. Output Swing, VS = ±15 V, G = +1

50ns/DIV

25mV/DIV

1.55V

1.5V

1.45V

VS = 3V

G = +1

VIN = 100mV STEP

Figure 33. Pulse Response, +VS = ±3 V, G = +1

100ns/DIV

500mV/DIV

–1V

VS = 5V

RL = 2kΩ

CL = 50pF

G = +2

VOUT = 2V p-p

Figure 34. Pulse Response, +VS = ±2.5 V, G = +2

100ns/DIV

500mV/DIV

2.5V

VS = 5V

G = +1

VOUT = 3V p-p

RL = 2kΩ

CL = 50pF

Figure 35. Pulse Response, +VS = ±2.5 V, G = +1

200ns/DIV

500mV/DIV

2.5V

VS = 5V

G = +1

RL = 2kΩ

CL = 470pF

Figure 36. Pulse Response, +VS = +5 V, G = +1, CL = 470 pF
