16 ABB general purpose drives ACS310 | Catalog

Options

How to select options

The options shown in the table below are available within

the ACS310 range. The control panels have an associated

4-figure option code, which is shown in the second column.

It is this code that replaces XXXX in the type code above.

*) To be ordered as separate item

The ACS310 is compatible with ACS-CP-C basic control panel Rev M or later.

The ACS310 is compatible with ACS-CP-A assistant control panel Rev E or later.

(New panel series manufactured since 2007 with serial number

XYYWWRXXXX, where year Y = 7 or greater and revision R = E, F, G, …)

Options

Ordering code

Description

Model

Protection class

68566398 *)

NEMA 1/UL type 1 (R0, R1, R2)

MUL1-R1

68566410 *)

NEMA 1/UL type 1 (R3)

MUL1-R3

3AUA0000023888 *)

NEMA 1/UL type 1 (R4)

MUL1-R4

Control panel

J400

Assistant control panel

ACS-CP-A

J404

Basic control panel

ACS-CP-C

Panel mounting kit

68294673 *)

Panel mounting kit

ACS/H-CP-EXT

3AUA0000013086 *)

Panel holder mounting kit

OPMP-01

Extension modules

L511

Relay output extension module. Option includes three (3)

additional relay outputs.

MREL-01

Tools

68566380 *)

FlashDrop tool

MFDT-01

64532871 *)

DriveWindow Light

External options

Input chokes

EMC filters

Output chokes

Remote monitoring

3AUA0000039179 *)

Ethernet adapter

SREA-01
