4. LCD Optical Characteristics .......................................................................................... 8

4.1 Optical specification .........................................................................................................................8

4.2 Measuring Condition.........................................................................................................................9

4.3 Measuring Equipment .......................................................................................................................9

5.

Electrical Characteristics............................................................................................ 10

5.1 Absolute Maximum Rating (Ta=25 VSS=0V) ...............................................................................10

5.2 DC Electrical Characteristics......................................................................................................... 11

5.3 LED Backlight Characteristics ...................................................................................................... 11

6. AC Characteristic .......................................................................................................... 13

6.1 Display Parallel 8/16-bit Interface Timing Characteristics (8080 system)..............................13

6.2 Display Serial Interface Timing Characteristics (3-line SPI system) ......................................15

6.3Display Serial Interface Timing Characteristics (4-line SPI system)........................................16

6.4 Parallel RGB Interface Timing Characteristics ...........................................................................17

6.5 Reset Timing Characteristics ........................................................................................................18

7. LCD Module Out-Going Quality Level ....................................................................... 20

7.1 VISUAL & FUNCTION INSPECTION STANDARD ........................................................................21

7.1.1 Inspection conditions .............................................................................................................................................21

7.1.2 Definition ...............................................................................................................................................................21

7.1.3 Sampling Plan .......................................................................................................................................................21

7.1.4 Criteria (Visual) ......................................................................................................................................................22

8. Reliability Test Result .................................................................................................. 26

8.1 Condition ..........................................................................................................................................26

9. Cautions and Handling Precautions .......................................................................... 27

9.1 Handling and Operating the Module ...........................................................................................27

9.2 Storage and Transportation. ..........................................................................................................27

10. Packing ......................................................................................................................... 28

* Description

This is a color active matrix TFT (Thin Film Transistor) LCD (liquid crystal display) that uses amorphous silico

n TFT as a switching device. This model is composed of a Transmissive type TFT-LCD Panel, driver circuit,

back-light unit. The resolution of a 1.77

’TFT-LCD contains 240x320 pixels, and can display up to 65K colors.

* Features

-Low Input Voltage: VCC:3.3V(TYP);IOVCC:2.8-3.3V

-Display Colors of TFT LCD: 65K colors

-Interface: 8/9/16/18Bit MCU;

3/4SPI+16/18Bit RGB

3-line/4-line Serial Interface
