69 / 89 page  Pushbuttons and Indicating Lights CA04716001E—March 2009 www.eaton.com 69 47 47 47 47 47 47 47 47 47 47 47 47 47 47 47 47 47 47 47 47 47 47 47 47 47 47 47 47 47 47 47.4 Pushbuttons and Indicating Lights M22 Modular Pushbuttons Palm Switches ASi Adapter Modules Momentary Maintained FAK-R-V-KC11-I General Standards IEC/EN 60947 VDE 0660 IEC/EN 60947 VDE 0660 IEC/EN 60947 VDE 0660 Lifespan, mechanical Operations x 106 >1 >0.1 >0.1 Operating frequency Operations/h ≥3600 ≥600 ≥600 Actuating force n 20–40 40–60 15–25 Operating torque Nm — — — Degree of protection, IEC/EN 60529 IP IP67, IP69K IP67, IP69K IP65 UL Type 4X, 13 4X, 13 4X, 13 Climatic proofing Damp heat, constant, to IEC 60068-2-78 Damp heat, cyclic, to IEC 60068-2-30 Ambient Temperature, Operating °F (°C) –73–104 (–25–40) –73–104 (–25–40) –73–104 (–25–40) Mounting position As required Mechanical shock resistance to IEC 60068-2-27 Shock duration 11 ms, half-sinusoidal g >15 >15 >15 M22-ASI M22-ASI-C General Standards IEC/EN 60947, DIN EN 50295 IEC/EN 60947, DIN EN 50295 Radio interference suppression EN 55011, EN 55022 EN 55011, EN 55022 Limit value class — — Protection type IP20 IP00 Climatic proofing Damp heat, constant, to IEC 60068-2-78, cyclical, to IEC 60068-2-30 Ambient Temperature, Operating °F (°C) –13–131 (–25–55) –13–131 (–25–55) Shock resistance Shock duration 11 ms g >30 >30 Vibration to IEC 60068-2-27 (amplitude 1 mm) Hz — — Dimensions mm — — Weight kg — — Mounting Front mounting Front mounting Mounting position As required As required Power supply Rated voltage to AS-Interface Specification Vdc 26.5–31.6 26.5–31.6 Connection technique Yellow plug-in terminal as insulation piercing terminal 2 cables on board Power supply Completely from the AS-Interface cable Addressing Via connection to AS-Interface cable Total power consumption of the AS-Interface mA ≥40 ≥40 AS-Interface — — Rated operational current at full load mA — — Rated operational current when idle (no I, O set) mA — — Status LEDs POWER AS-Interface cable: green LED on the rear side of the element ERROR AS-Interface, AS-Interface Master failure: red LED on the rear side of the element POWER AS-Interface cable: green LED on the board ERROR AS-Interface, AS-Interface Master failure: red LED on the board |
|
