1. Scope

This data sheet is to introduce the specification of

MCT0096A0W80160PMLIPS active matrix TFT

module. It is composed of a color TFT-LCD panel, driver IC, FPC and a backlight unit. The 0.96′′

display area contains 80 (RGB) x 160 pixels.

2. Application

Digital equipments which need color display, mobile navigator/video systems.

3. General Information

Item

Contents

Unit

Size

0.96

inch

Resolution

80 (RGB) x 160

/

Interface

4‐Line SPI Interface

/

Technology type

IPS

/

Pixel pitch

0.135 x 0.135

mm

Pixel Configuration

R.G.B. Vertical Stripe

Outline Dimension (W x H x D)

13.30 x 27.948 x 1.40

mm

Active Area

10.80 x 21.696

mm

Display Mode

Transmissive

/

Driver IC

ST7735S

Viewing Direction

Free

Backlight Type

LED

/

Weight

TBD

g
