Data Sheet
ADP1972
CH1 10.0V CH2 5.0V
5.0GS/s
CH3 5.0V
CH4 5.0V
10M POINTS
100µs
CH1
7.00V
1
2
3
4
T 14.42%
T
EN
DL
VREG
SYNC
VIN = 24V
VCOMP = 2.5V
NO CSS
Figure 15. Startup
Rev. B | Page 9 of 18
