IP101G
Data Sheet
9
Physical Dimensions
9.1 48-PIN LQFP
63/65
January 14, 2014
Copyright © 2011, IC Plus Corp.
IP101G-DS-R01
F
SEATING
PLANE
1
12
13
24
25
36
37
48
Top view
E
E1
12"
12"
b
e
F y
1
12
13
24
25
36
37
48
L
L1
GAUGE PLANE
DETAIL "E"
"E"
θ
mm
inch
A
A1
1.600MAX.
A2
0.050~0.150
0.0630MAX.
b
1.400 0.05
0.0020~0.0059
c
0.200TYP
0.0551 0.0020
D1
0.127TYP
0.0078TYP
E1
e
D
0.500TYP
0.0050TYP
Unit
Symbols
y
L1
L
E
0"~7"
0.100MAX.
1.000REF
0.600 0.150
0"~7"
0.0039MAX.
0.0393REF
0.0236 0.006
0.0196TYP
+
-
+
-
0.2756 0.0039
+
-
7.000 0.100
+
-
7.000 0.100
+
-
0.2756 0.0039
+
-
+
-
+
-
9.000 0.250
0.3543 0.0098
+
-
+
-
9.000 0.250
0.3543 0.0098
+
-
+
-
Notes:
1. DIMENSION D1 & E1 DO NOT INCLUDE MOLD FLASH OR PROTRUSION.
2. DIMENSION b DOES NOT INCLUDE DAMBAR PROTRUSION.
3. MAX. END FLASH IS 0.15mm.
4. MAX. DAMBAR PROTRUSION IS 0.13mm.
GENERAL APPEARANCE SPEC SHOULD BE BASED ON FINAL VISUAL INSPECTION SPEC.
2
Bottom view
Figure 24 48-PIN LQFP Dimension
