ADL5812

Rev. 0 | Page 15 of 28

700

900 1100 1300 1500 1700 1900 2100 2300 2500 2700

RF FREQUENCY (MHz)

LPF = 0

LPF = 1

LPF = 2

LPF = 3

Figure 49. Conversion Gain vs. RF Frequency for All LPF Settings,

RFB and VGS Use Optimum Settings

700

900 1100 1300 1500 1700 1900 2100 2300 2500 2700

RF FREQUENCY (MHz)

LPF = 0

LPF = 1

LPF = 2

LPF = 3

Figure 50. Input IP3 vs. RF Frequency for All LPF Settings,

RFB and VGS Use Optimum Settings

700

900 1100 1300 1500 1700 1900 2100 2300 2500 2700

RF FREQUENCY (MHz)

LPF = 0

LPF = 1

LPF = 2

LPF = 3

Figure 51. Input P1dB vs. RF Frequency for All LPF Settings,

RFB and VGS Use Optimum Settings

700

900 1100 1300 1500 1700 1900 2100 2300 2500 2700

RF FREQUENCY (MHz)

LPF = 0

LPF = 1

LPF = 2

LPF = 3

Figure 52. Noise Figure vs. RF Frequency for All LPF Settings,

RFB and VGS Use Optimum Settings.
