39 / 47 page  7.4 SO-8 packaging information Figure 55. SO-8 tape and reel shipment (suffix “TR”) Tape dimensions According to electronic industries association (EIA) standard 481 rev.A, feb.1986 Tape width W 12 Tape hole spacing P0 (± 0.1) 4 Component spacing P 8 Hole diameter D (+0.1/-0) 1.5 Hole diameter D1 (min) 1.5 Hole position F ( ± 0.05) 5.5 Compartment depth K (max) 4.5 Hole spacing P1 (± 0.1 ) 2 Top cover tape End Sta rt No components No components Components 50 0mm mi n Empty components pockets 500 mm min sealed with cover tape. User direction of feed Reel dimensions All dimensions are in mm. Base q.ty 25 00 Bulk q.ty 25 00 A (max) 330 B (min) 1.5 C (± 0.2) 13 F 20. 2 G (+2/-0) 12. 4 N (min) 60 T (max) 18. 4 All dimensions are in mm. L99VR01 SO-8 packaging information DS13649 - Rev 3 page 39/47 |
|
