DataS h eet

February 27, 2015, MB9B410R-DS706-00026-3v0-E

113

CONFIDENTIAL

120-pin plastic LQFP

Lead pitch

0.50 mm

Package width ×

package length

16.0 mm × 16.0 mm

Lead shape

Gullwing

Sealing method

Plastic mold

Mounting height

1.70 mm Max

Weight

0.88 g

Code

(Reference)

P-LFQFP120-16 × 16-0.50

120-pin plastic LQFP

(FPT-120P-M37)

2010 FUJITSU SEMICONDUCTOR LIMITED F120037Sc(1)-1-1

16.00 ± 0.10(.630 ± .004) SQ

18.00 ± 0.20(.709 ± .008) SQ

120

0.50(.020)

0.22± 0.05

(.009± .002)

0.08(.003)

(

)

0.08(.003)

"A"

INDEX

.059–.004

+.008

–0.10

+0.20

1.50

(Mounting height)

0˚~8˚

(.024± .006)

0.60 ± 0.15

0.25(.010)

0.10 ± 0.05

(.004± .002)

Details of "A" part

(Stand off)

LEAD No.

–0.03

+0.05

0.145

–.001

+.002

.006

Dimensions in mm (inches).

Note: The values in parentheses are reference values

Note 1) * : These dimensions do not include resin protrusion.

Note 2) Pins width and pins thickness include plating thickness.

Note 3) Pins width do not include tie bar cutting remainder.
