AB18X5 Real-Time Clock with Power
Management Family
Date of Issue: October 16, 2014
3.0 x 3.0 mm
Page 20 of 37
Abracon Drawing #453568
Revision: C
Figure 11 shows the typical VCC power state operating current with a 32.768 kHz clock output on the
CLKOUT pin. Test conditions: TA = 25 °C, All inputs and outputs except CLKOUT are at 0 V or VCC. 15 pF
capacitive load on the CLKOUT pin.
Figure 11. Typical VCC Current vs. Voltage, 32.768 kHz Clock Output
0
1
2
3
4
5
1.8
2
2.2
2.4
2.6
2.8
3
3.2
3.4
3.6
VCC Voltage (V)
TA = 25 °C
