Electrical characteristics
SPC560D30x, SPC56040Dx
54/90
Doc ID 16315 Rev 7
Static latch-up (LU)
Two complementary static tests are required on six parts to assess the latch-up
performance:
●
A supply overvoltage is applied to each power supply pin.
●
A current injection is applied to each input, output and configurable I/O pin.
These tests are compliant with the EIA/JESD 78 IC latch-up standard.
Table 35.
Latch-up results
Symbol
C
Parameter
Conditions
Class
LU
CC
T
Static latch-up class
TA = 125 °C
conforming to JESD 78
II level A
