Revision history

SPC560D30x, SPC560D40x

88/90

Doc ID 16315 Rev 7

16-Sep-2011

(cont.)

MEDIUM configuration output buffer electrical characteristics:

changed “IOH = 100 µA” to “IOL = 100 µA” in VOL conditions

I/O consumption: replaced instances of “Root medium square” with

“Root mean square”

Updated section “Voltage regulator electrical characteristics”

Section “Low voltage detector electrical characteristics”: changed

title (was “Voltage monitor electrical characteristics”); added a fifth

LVD (LVDHV3B); added event status flag names found in RGM

chapter of device reference manual to POR module and LVD

descriptions; replaced instances of “Low voltage monitor” with “Low

voltage detector”; deleted note referencing power domain No. 2 (this

domain is not present on the device); updated electrical

characteristics table

Updated and renamed section “Power consumption” (was previously

section “Low voltage domain power consumption”)

Program and erase specifications (code flash): updated symbols;

updated tesus values

Updated Flash memory read access timing

EMI radiated emission measurement: updated SEMI values

Updated FMPLL electrical characteristics

Crystal oscillator and resonator connection scheme: inserted

footnote about possibly requiring a series resistor

Fast internal RC oscillator (16 MHz) electrical characteristics:

updated tFIRCSU values

Section “Input impedance and ADC accuracy”: changed “VA/VA2” to

“VA2/VA” in Equation 13

ADC conversion characteristics:

– updated conditions for sampling time VDD = 5.0 V

– updated conditions for conversion time VDD =5.0 V

Updated Abbreviations

Removed Order codes tables.

01-Dec-2011

Replaced “TBD” with “8.21 mA” in IDD_HV(FLASH) cell of On-chip

peripherals current consumption table

Table 51.

Document revision history (continued)

Date

Revision

Changes
