SPC560D30x, SPC56040Dx

Electrical characteristics

Doc ID 16315 Rev 7

51/90

ECC circuitry provides correction of single bit faults and is used to improve further

automotive reliability results. Some units will experience single bit corrections throughout

the life of the product with no impact to product reliability.

4.11.2

Flash power supply DC characteristics

Table 31 shows the power supply DC characteristics on external supply.

Note:

Power supply for data flash is actually provided by code flash; this means that data flash

cannot work if code flash is not powered.

4.11.3

Start-up/Switch-off timings

Table 30.

Flash memory read access timing

Symbol

Parameter

Conditions

(1)

Max Unit

fCFREAD CC

P Maximum working frequency for reading code flash memory at given

number of wait states in worst conditions

2 wait states

MHz

0 wait states

fDFREAD CC P

Maximum working frequency for reading data flash memory at given

number of wait states in worst conditions

6 wait states

MHz

VDD = 3.3 V ± 10% / 5.0 V ± 10%, TA = 40 to 125 °C, unless otherwise specified

Table 31.

Flash power supply DC electrical characteristics

Symbol

Parameter

Conditions(1)

Value

Unit

Min Typ Max

ICFREAD CC D Sum of the current consumption on

VDDHV and VDDBV on read access

Flash module read

fCPU = 48 MHz

Code flash

—

IDFREAD CC D

Data flash

—

ICFMOD CC D Sum of the current consumption on

VDDHV and VDDBV on matrix

modification (program/erase)

Program/Erase on-going

while reading flash registers,

fCPU = 48 MHz

Code flash

—

IDFMOD CC D

Data flash

—

IFLPW CC D

Sum of the current consumption on

VDDHV and VDDBV during

flash low-power mode

—

Code flash

—

910

µA

ICFPWD CC D Sum of the current consumption on

VDDHV and VDDBV during

flash power-down mode

—

Code flash

—

125

µA

IDFPWD CC D

Data flash

—

µA

VDD = 3.3 V ± 10% / 5.0 V ± 10%, TA = 40 to 125 °C, unless otherwise specified

Table 32.

Start-up time/Switch-off time

Symbol

Parameter

Conditions(1)

Value

Unit

Min

Typ

Max

tFLARSTEXIT

T Delay for flash module to exit reset mode

Code flash

—

125

µs

Data flash

—

150

µs
