SPC560D30x, SPC56040Dx

Package pinouts and signal descriptions

Doc ID 16315 Rev 7

15/90

3.4

Pad types

In the device the following types of pads are available for system pins and functional port

pins:

S = Slow(a)

M = Medium(a) (b)

F = Fast(a) (b)

I = Input only with analog feature(a)

J = Input/Output (‘S’ pad) with analog feature

X = Oscillator

3.5

System pins

The system pins are listed in Table 5.

Table 4.

Voltage supply pin descriptions

Port pin

Function

Pin number

LQFP64

LQFP100

VDD_HV

Digital supply voltage

7, 28, 34, 56

15, 37, 52, 70, 84

VSS_HV

Digital ground

6, 8, 26, 33, 55

14, 16, 35, 51, 69,

VDD_LV

1.2V decoupling pins. Decoupling capacitor must be

connected between these pins and the nearest VSS_LV

pin.(1)

11, 23, 57

19, 32, 85

VSS_LV

1.2V decoupling pins. Decoupling capacitor must be

connected between these pins and the nearest VDD_LV

pin.(1)

10, 24, 58

18, 33, 86

VDD_BV

Internal regulator supply voltage

A decoupling capacitor must be placed between each of the three VDD_LV/VSS_LV supply pairs to ensure stable voltage

(see the recommended operating conditions in the device datasheet for details).

See the I/O pad electrical characteristics in the device datasheet for details.

All medium and fast pads are in slow configuration by default at reset and can be configured as fast or medium

(see the PCR[SRC] description in the device reference manual).

Table 5.

System pin descriptions

Port pin

Function

I/O

direction

Pad type

RESET

configuration

Pin number

LQFP64

LQFP100

RESET

Bidirectional reset with Schmitt-Trigger

characteristics and noise filter.

I/O

Input, weak

pull-up only

after PHASE2

917
