STLS2F01
I/O bus interface description
19/48
The read and write timing are shown in the Figure 5 and Figure 6. When the data width is
16-bit, the output address can be generated by shifting the physical address right one bit.
Figure 5.
Local bus read timing
.
lioden
liodir
lioadlock
liocs
pciclk
lioaddr
lioad
liord
addr[7:0]
addr[7:0]+1
addr[23..8]data
data
