AS3661 datasheet(61/87 Pages) AMSCO

61 / 87 page

www.austriamicrosystems.com

Revision 1.3

60 - 85

AS3661

Datasheet - D e t a i l e d D e s c r i p t i o n

8.10.28 PROG MEM PAGE SELECT

8.10.29 ENG1 MAPPING MSB

8.10.30 71H ENG1 MAPPING LSB

Table 63. PROG MEM PAGE SEL Register

PROG MEM PAGE SEL

Bit

Bit Name

Default

Access

Bit Description

2:0

PAGE_SEL

000

R/W

These bits select the program memory page. The program

memory is divided into six pages of 16 instructions; thus the

total amount of the program memory is 96 instructions.

000: Program Memory 0x00 - 0x0F selected.

001: Program Memory 0x10 - 0x1F selected.

010: Program Memory 0x20 - 0x2F selected.

011: Program Memory 0x30 - 0x3F selected.

100: Program Memory 0x40 - 0x4F selected.

101: Program Memory 0x50 - 0x5F selected.

Table 64. ENG1 MAPPING MSB Register

ENG1 MAPPING MSB

Bit

Bit Name

Default

Access

Bit Description

ENG1_GPO

0: GPO pin non-mapped to the program exec. engine 1.

1: GPO pin is mapped to the program execution engine 1.

ENG1_LED9

0: LED9 pin non-mapped to the program exec. engine1.

1: LED9 pin is mapped to the program execution engine 1.

Table 65. ENG1 MAPPING LSB Register

ENG1 MAPPING LSB

Bit

Bit Name

Default

Access

Bit Description

ENG1_LED8

0: LED8 pin non-mapped to the program exec. engine 1.

1: LED8 pin is mapped to the program execution engine 1.

ENG1_LED7

0: LED7 pin non-mapped to the program exec. engine 1.

1: LED7 pin is mapped to the program execution engine 1.

ENG1_LED6

0: LED6 pin non-mapped to the program exec. engine 1.

1: LED6 pin is mapped to the program execution engine1.

ENG1_LED5

0: LED5 pin non-mapped to the program exec. engine 1.

1: LED5 pin is mapped to the program execution engine 1.

ENG1_LED4

0: LED4 pin non-mapped to the program exec. engine 1.

1: LED4 pin is mapped to the program execution engine 1.

ENG1_LED3

0: LED3 pin non-mapped to the program exec. engine 1.

1: LED3 pin is mapped to the program execution engine 1.

ENG1_LED2

0: LED2 pin non-mapped to the program exec. engine 1.

1: LED2 pin is mapped to the program execution engine 1.

ENG1_LED1

0: LED1 pin non-mapped to the program exec. engine 1.

1: LED1 pin is mapped to the program execution engine 1.
