background image
EM342
58
Rev 1.0
GPIO_PAOUT: Address: 0x4000B00C Reset: 0x0
GPIO_PBOUT: Address: 0x4000B40C Reset: 0x0
GPIO_PCOUT: Address: 0x4000B80C Reset: 0x0
Register 7.4. GPIO_PxOUT
GPIO_PAOUT: Port A Output Data Register
GPIO_PBOUT: Port B Output Data Register
GPIO_PCOUT: Port C Output Data Register
Bit
31
30
29
28
27
26
25
24
Name
0
0
0
0
0
0
0
0
Bit
23
22
21
20
19
18
17
16
Name
0
0
0
0
0
0
0
0
Bit
15
14
13
12
11
10
9
8
Name
0
0
0
0
0
0
0
0
Bit
7
6
5
4
3
2
1
0
Name
Px7
Px6
Px5
Px4
Px3
Px2
Px1
Px0
Bitname
Bitfield Access
Description
Px7
[7]
RW
Output data for Px7.
Px6
[6]
RW
Output data for Px6.
Px5
[5]
RW
Output data for Px5.
Px4
[4]
RW
Output data for Px4.
Px3
[3]
RW
Output data for Px3.
Px2
[2]
RW
Output data for Px2.
Px1
[1]
RW
Output data for Px1.
Px0
[0]
RW
Output data for Px0.
