8.4.2. Set Up and Configuration

The UART baud rate clock is produced by a programmable baud generator starting from the 24 Hz clock:

The integer portion of the divisor, N, is written to the SC1_UARTPER register and the fractional part, F, to the

SC1_UARTFRAC register. Table 8.5 shows the values used to generate some common baud rates and their

associated clock frequency error. The UART requires an internal clock that is at least eight times the baud rate

clock, so the minimum allowable setting for SC1_UARTPER is 8.

The UART can miss bytes when the inter-byte gap is long or there is a baud rate mismatch between receiver and

transmitter. The UART may detect a parity and/or framing error on the corrupted byte, but there will not necessarily

be any error detected.

The UART is best operated in systems where the other side of the communication link also uses a crystal as its

timing reference, and baud rates should be selected to minimize the baud rate mismatch to the crystal tolerance.

Additionally, UART protocols should contain some form of error checking (for example CRC) at the packet level to

detect, and retry in the event of errors. Since the probability of corruption is low, there would only be a small effect

on UART throughput due to retries.

Errors may occur when:

Table 8.5. UART Baud Rate Divisors for Common Baud Rates

Baud Rate

(bits/sec)

SC1_UARTPER

SC1_UARTFRAC

Baud Rate Error (%)

300

40000

2400

5000

4800

2500

9600

1250

19200

625

38400

312

57600

208

– 0.08

115200

104

+ 0.16

230400

+ 0.16

460800

+ 0.16

921600

+ 0.16

baud

24 MHz

2N F

--------------------

Tgap

baud Ferror



--------------------------------------

Where:

Tgap= inter-byte gap in seconds

baud = baud rate in bps

Ferror = relative frequency error in ppm


