EM342

Rev 1.0

Table 5.2 shows the mapping of the option bytes that are used for read and write protection of the flash. Each bit of

the flash write protection option bytes protects a 4 page region of the main flash block. The EM342 has 16 regions

and therefore option bytes 4 and 5 control flash write protection.These write protection bits are active low, and

therefore the erased state of 0xFF disables write protection. Like read protection, write protection only takes effect

after a reset. Write protection not only prevents a write to the region, but also prevents page erasure.

Option byte 0 controls flash read protection. When option byte 0 is set to 0xA5, read protection is disabled. All other

values, including the erased state 0xFF, enable read protection when coming out of reset. The internal state of read

protection (active versus disabled) can only be changed by applying a full chip reset. If a debugger is connected to

the EM342, the intrusion state is latched. Read protection is combined with this latched intrusion signal. When both

read protection and intrusion are set, all flash is disconnected from the internal bus. As a side effect, the CPU

cannot execute code since all flash is disconnected from the bus. This functionality prevents a debug tool from

being able to read the contents of any flash. The only means of clearing the intrusion signal is to disconnect the

debugger and reset the entire chip using the nRESET pin. By requiring a chip reset, a debugger cannot install or

execute malicious code that could allow the contents of the flash to be read.

The only way to disable read protection is to program option byte 0 with the value 0xA5. Option byte 0 must be

erased before it can be programmed. Erasing option byte 0 while read protection is active automatically mass-

erases the main flash block. By automatically erasing main flash, a debugger cannot disable read protection and

readout the contents of main flash without destroying its contents.

When read protection is active, the bottom four flash pages, addresses 0x08000000 to 0x08001FFF, are

automatically write-protected. Write protecting the bottom four flash pages of main flash prevents an attacker from

reprogramming the reset vector and executing arbitrary code.

In general, if read protection is active then write protection should also be active. This prevents an attacker from

reprogramming flash with malicious code that could readout the flash after the debugger is disconnected. Even

though read protection automatically protects the reset vector, the same technique of reprogramming flash could

be performed at an address outside the bottom four flash pages. To obtain fully protected flash, both read

protection and write protection should be active.

Table 5.1. Option Byte Storage

Address

bits [15:8]

bits [7:0]

Notes

0x08040800 Inverse Option Byte 0

Option Byte 0 Configures flash read protection

0x08040802 Inverse Option Byte 1

Option Byte 1 Reserved

0x08040804 Inverse Option Byte 2

Option Byte 2 Available for customer use1

0x08040806 Inverse Option Byte 3

Option Byte 3 Available for customer use1

0x08040808 Inverse Option Byte 4

Option Byte 4 Configures flash write protection

0x0804080A Inverse Option Byte 5

Option byte 5 Configures flash write protection

0x0804080C Inverse Option Byte 6

Option Byte 6 Reserved

0x0804080E Inverse Option Byte 7

Option Byte 7 Reserved

Notes:

1. Option bytes 2 and 3 do not link to any specific hardware functionality other than the option byte loader.

Therefore, they are best used for storing data that requires a hardware verification of the data integrity.
