EM342
Rev 1.0
61
GPIO_PAWAKE: Address: 0x4000BC08 Reset: 0x0
GPIO_PBWAKE: Address: 0x4000BC0C Reset: 0x0
GPIO_PCWAKE: Address: 0x4000BC10 Reset: 0x0
Register 7.7. GPIO_PxWAKE
GPIO_PAWAKE: Port A Wakeup Monitor Register
GPIO_PBWAKE: Port B Wakeup Monitor Register
GPIO_PCWAKE: Port C Wakeup Monitor Register
Bit
31
30
29
28
27
26
25
24
Name
0
0
0
0
0
0
0
0
Bit
23
22
21
20
19
18
17
16
Name
0
0
0
0
0
0
0
0
Bit
15
14
13
12
11
10
9
8
Name
0
0
0
0
0
0
0
0
Bit
7
6
5
4
3
2
1
0
Name
Px7
Px6
Px5
Px4
Px3
Px2
Px1
Px0
Bitname
Bitfield
Access
Description
Px7
[7]
RW
Write 1 to enable wakeup monitoring of Px7.
Px6
[6]
RW
Write 1 to enable wakeup monitoring of Px6.
Px5
[5]
RW
Write 1 to enable wakeup monitoring of Px5.
Px4
[4]
RW
Write 1 to enable wakeup monitoring of Px4.
Px3
[3]
RW
Write 1 to enable wakeup monitoring of Px3.
Px2
[2]
RW
Write 1 to enable wakeup monitoring of Px2.
Px1
[1]
RW
Write 1 to enable wakeup monitoring of Px1.
Px0
[0]
RW
Write 1 to enable wakeup monitoring of Px0.
