38 / 143 page  EM342 38 Rev 1.0 Table 6.5 shows which reset sources generate certain resets. 6.3. Clocks The EM342 integrates four oscillators: 12 MHz RC oscillator 24 MHz crystal oscillator 10 kHz RC oscillator 32.768 kHz crystal oscillator Figure 6.2 shows a block diagram of the clocks in the EM342. This simplified view shows all the clock sources and the general areas of the chip to which they are routed. Table 6.5. Generated Resets Reset Source Reset Generation Module Output PORESET SYSRESET DAPRESET PRESETHV PRESETLV POR HV X X X X X POR LV (due to waking from normal deep sleep) X X X X POR LV (not due to waking from normal deep sleep) X X X X X nRESET X X X X Watchdog X X X SYSRESETREQ X X X Option byte error X X X Normal deep sleep X X X X Emulated deep sleep X X Debug reset X |
|
