PA5

I/O

Digital I/O

PTI_DATA

Data signal of Packet Trace Interface (PTI)

Disable trace interface in ARM core

Enable PTI in Ember software

Select alternate output function with GPIO_PACFGH[7:4]

nBOOTMODE

Activate FIB monitor instead of main program or bootloader when coming

out of reset.

Signal is active during and immediately after a reset on nRESET. See "7.5.

Boot Configuration" on page 51.

TRACEDATA3

Synchronous CPU trace data bit 3

Select 4-wire synchronous trace interface in ARM core

Enable trace interface in ARM core

Select alternate output function with GPIO_PACFGH[7:4]

VDD_PADS

Power

Pads supply (2.1–3.6 V)

Do not connect

PB1

I/O

Digital I/O

SC1MISO

SPI slave data out of Serial Controller 1

Select SPI with SC1_MODE

Select slave with SC1_SPICR

Select alternate output function with GPIO_PBCFGL[7:4]

SC1TXD

UART transmit data of Serial Controller 1

Select UART with SC1_MODE

Select alternate output function with GPIO_PBCFGL[7:4]

PB2

I/O

Digital I/O

SC1MOSI

SPI slave data in of Serial Controller 1

Select SPI with SC1_MODE

Select slave with SC1_SPICR

SC1RXD

UART receive data of Serial Controller 1

Select UART with SC1_MODE

SWCLK

I/O

Serial Wire clock input/output with debugger

Selected when in Serial Wire mode (see JTMS description, Pin 35)

JTCK

JTAG clock input from debugger

Selected when in JTAG mode (default mode, see JTMS description,

Pin 35)

Internal pull-down is enabled
