background image
MB96340 Series
Document Number: 002-04579 Rev. *A
Page 34 of 109
0003B9H
Memory Patch function - Patch address 0 middle
PFAM0
R/W
0003BAH
Memory Patch function - Patch address 0 high
PFAH0
R/W
0003BBH
Memory Patch function - Patch address 1 low
PFAL1
R/W
0003BCH
Memory Patch function - Patch address 1 middle
PFAM1
R/W
0003BDH
Memory Patch function - Patch address 1 high
PFAH1
R/W
0003BEH
Memory Patch function - Patch address 2 low
PFAL2
R/W
0003BFH
Memory Patch function - Patch address 2 middle
PFAM2
R/W
0003C0H
Memory Patch function - Patch address 2 high
PFAH2
R/W
0003C1H
Memory Patch function - Patch address 3 low
PFAL3
R/W
0003C2H
Memory Patch function - Patch address 3 middle
PFAM3
R/W
0003C3H
Memory Patch function - Patch address 3 high
PFAH3
R/W
0003C4H
Memory Patch function - Patch address 4 low
PFAL4
R/W
0003C5H
Memory Patch function - Patch address 4 middle
PFAM4
R/W
0003C6H
Memory Patch function - Patch address 4 high
PFAH4
R/W
0003C7H
Memory Patch function - Patch address 5 low
PFAL5
R/W
0003C8H
Memory Patch function - Patch address 5 middle
PFAM5
R/W
0003C9H
Memory Patch function - Patch address 5 high
PFAH5
R/W
0003CAH
Memory Patch function - Patch address 6 low
PFAL6
R/W
0003CBH
Memory Patch function - Patch address 6 middle
PFAM6
R/W
0003CCH
Memory Patch function - Patch address 6 high
PFAH6
R/W
0003CDH
Memory Patch function - Patch address 7 low
PFAL7
R/W
0003CEH
Memory Patch function - Patch address 7 middle
PFAM7
R/W
0003CFH
Memory Patch function - Patch address 7 high
PFAH7
R/W
0003D0H
Memory Patch function - Patch data 0 Low
PFDL0
PFD0
R/W
0003D1H
Memory Patch function - Patch data 0 High
PFDH0
R/W
0003D2H
Memory Patch function - Patch data 1 Low
PFDL1
PFD1
R/W
0003D3H
Memory Patch function - Patch data 1 High
PFDH1
R/W
0003D4H
Memory Patch function - Patch data 2 Low
PFDL2
PFD2
R/W
0003D5H
Memory Patch function - Patch data 2 High
PFDH2
R/W
0003D6H
Memory Patch function - Patch data 3 Low
PFDL3
PFD3
R/W
0003D7H
Memory Patch function - Patch data 3 High
PFDH3
R/W
0003D8H
Memory Patch function - Patch data 4 Low
PFDL4
PFD4
R/W
Table 4: I/O map MB96(F)34x
Address
Register
Abbreviation
8-bit access
Abbreviation
16-bit access
Access
