MB96F348CWCPMC-GSE2 Datasheet(PDF) 85 Page - Cypress Semiconductor |
|
|
|||||||||||||||||||||||||||||
MB96F348CWCPMC-GSE2 Datasheet(HTML) 85 Page - Cypress Semiconductor |
|
|
85 / 109 page  MB96340 Series Document Number: 002-04579 Rev. *A Page 85 of 109 14.4.12 USART timing WARNING: The values given below are for an I/O driving strength IOdrive = 5mA. If IOdrive is 2mA, all the maximum output timing described in the different tables must then be increased by 10ns. Notes: ■ AC characteristic in CLK synchronized mode. ■ CL is the load capacity value of pins when testing. ■ Depending on the used machine clock frequency, the maximum possible baud rate can be limited by some parameters. These parameters are shown in “MB96300 Super series HARDWARE MANUAL”. ■ tCLKP1 is the cycle time of the peripheral clock 1 (CLKP1), Unit : ns [1]: Parameter N depends on tSCYCI and can be calculated as follows: ■ if tSCYCI = 2*k*tCLKP1, then N = k, where k is an integer > 2 ■ if tSCYCI = (2*k+1)*tCLKP1, then N = k+1, where k is an integer > 1 Examples: (TA = -40°C to 125°C, VCC = 3.0V to 5.5V, VSS = AVSS = 0V, IOdrive = 5mA, CL = 50pF) Parameter Symbol Pin Condition VCC = AVCC= 4.5V to 5.5V VCC = AVCC= 3.0V to 4.5V Unit Min Max Min Max Serial clock cycle time tSCYCI SCKn Internal Shift Clock Mode 4 tCLKP1 -4 tCLKP1 -ns SCK ↓→ SOT delay time tSLOVI SCKn, SOTn -20 20 -30 30 ns SOT → SCK ↑ delay time tOVSHI SCKn, SOTn N*tCLKP1 - 20 [1] -N*tCLKP1 - 30 [1] -ns Valid SIN → SCK ↑ tIVSHI SCKn, SINn tCLKP1 + 45 - tCLKP1 + 55 - ns SCK ↑→ Valid SIN hold time tSHIXI SCKn, SINn 0-0 - ns Serial clock “L” pulse width tSLSHE SCKn External Shift Clock Mode tCLKP1 + 10 - tCLKP1 + 10 - ns Serial clock “H” pulse width tSHSLE SCKn tCLKP1 + 10 - tCLKP1 + 10 - ns SCK ↓→ SOT delay time tSLOVE SCKn, SOTn -2 tCLKP1 + 45 - 2 tCLKP1 + 55 ns Valid SIN → SCK ↑ tIVSHE SCKn, SINn tCLKP1/2 + 10 - tCLKP1/2 + 10 - ns SCK ↑→ Valid SIN hold time tSHIXE SCKn, SINn tCLKP1 + 10 - tCLKP1 + 10 - ns SCK fall time tFE SCKn - 20 - 20 ns SCK rise time tRE SCKn - 20 - 20 ns tSCYCI N 4*tCLKP1 2 5*tCLKP1, 3 7*tCLKP1, 4 ... ... |
|
