MB96F348CWCPMC-GSE2 Datasheet(PDF) 6 Page - Cypress Semiconductor |
|
|
|||||||||||||||||||||||||||||
MB96F348CWCPMC-GSE2 Datasheet(HTML) 6 Page - Cypress Semiconductor |
|
|
6 / 109 page  MB96340 Series Document Number: 002-04579 Rev. *A Page 6 of 109 1. Product Lineup Features MB96V300B MB96(F)34x Product type Evaluation sample Flash product: MB96F34x Mask ROM product: MB9634x Product options YS NA Low voltage reset persistently on / Single clock RS Low voltage reset can be disabled / Single clock YW Low voltage reset persistently on / Dual clock RW Low voltage reset can be disabled / Dual clock TS indep. 32KB Flash / Low voltage reset persistently on / Single clock HS indep. 32KB Flash / Low voltage reset can be disabled / Single clock TW indep. 32KB Flash / Low voltage reset persistently on / Dual clock HW indep. 32KB Flash / Low voltage reset can be disabled / Dual clock FS 64KB Data Flash / Low voltage reset persistently on / Single clock DS 64KB Data Flash / Low voltage reset can be disabled / Single clock FW 64KB Data Flash / Low voltage reset persistently on / Dual clock DW 64KB Data Flash / Low voltage reset can be disabled / Dual clock AS No CAN / Low voltage reset can be disabled / Single clock devices CS No CAN / indep. 32KB Flash / Low voltage reset can be disabled / Single clock AW No CAN / Low voltage reset can be disabled / Dual clock CW No CAN / indep. 32KB Flash / Low voltage reset can be disabled / Dual clock Flash/ROM RAM 160KB 8KB ROM/Flash memory emulation by external RAM, 92KB internal RAM MB96345Y [1], MB96345R [1] 224KB [Flash A: 160KB, Data Flash A: 64KB] 8KB MB96F345F [1], MB96F345D [1] 288KB 16KB MB96F346Y, MB96346Y [1], MB96F346R, MB96346R [1], MB96F346A 416KB 16KB MB96F347Y, MB96F347R, MB96F347A 544KB 24KB MB96F348Y, MB96F348R, MB96F348A 576KB [Flash A: 544KB, Flash B: 32KB] 24KB MB96F348T, MB96F348H, MB96F348C Package BGA416 FPT-100P-M20 FPT-100P-M22 DMA 16 channels 6 channels USART 10 channels 7 channels |
|
