MB96F348CWCPMC-GSE2 Datasheet(PDF) 36 Page - Cypress Semiconductor |
|
|
|||||||||||||||||||||||||||||
MB96F348CWCPMC-GSE2 Datasheet(HTML) 36 Page - Cypress Semiconductor |
|
|
36 / 109 page  MB96340 Series Document Number: 002-04579 Rev. *A Page 36 of 109 000407H PLL Control register High PLLCRH R/W 000408H RC clock timer control register RCTCR R/W 000409H Main clock timer control register MCTCR R/W 00040AH Sub clock timer control register SCTCR R/W 00040BH Reset cause and clock status register with clear function RCCSRC R 00040CH Reset configuration register RCR R/W 00040DH Reset cause and clock status register RCCSR R 00040EH Watch dog timer configuration register WDTC R/W 00040FH Watch dog timer clear pattern register WDTCP W 000410H-000414H Reserved - 000415H Clock output activation register COAR R/W 000416H Clock output configuration register 0 COCR0 R/W 000417H Clock output configuration register 1 COCR1 R/W 000418H Clock Modulator control register CMCR R/W 000419H Reserved - 00041AH Clock Modulator Parameter register Low CMPRL CMPR R/W 00041BH Clock Modulator Parameter register High CMPRH R/W 00041CH-00042BH Reserved - 00042CH Voltage Regulator Control register VRCR R/W 00042DH Clock Input and LVD Control Register CILCR R/W 00042EH-00042FH Reserved - 000430H I/O Port P00 - Data Direction Register DDR00 R/W 000431H I/O Port P01 - Data Direction Register DDR01 R/W 000432H I/O Port P02 - Data Direction Register DDR02 R/W 000433H I/O Port P03 - Data Direction Register DDR03 R/W 000434H I/O Port P04 - Data Direction Register DDR04 R/W 000435H I/O Port P05 - Data Direction Register DDR05 R/W 000436H I/O Port P06 - Data Direction Register DDR06 R/W 000437H I/O Port P07 - Data Direction Register DDR07 R/W 000438H I/O Port P08 - Data Direction Register DDR08 R/W 000439H I/O Port P09 - Data Direction Register DDR09 R/W 00043AH I/O Port P10 - Data Direction Register DDR10 R/W Table 4: I/O map MB96(F)34x Address Register Abbreviation 8-bit access Abbreviation 16-bit access Access |
|
