MB96340 Series

Document Number: 002-04579 Rev. *A

Page 107 of 109

2009-01-09

■ Format adjusted to official Cypress datasheet standard (mainly style changes and official notes

and disclaimer added)

■ Numbering of Electrical Characteristics subchapters automated

■ Note about devices under development modified

■ I/O map: Note added about reserved addresses

■ ICCSPLL for CLKS1=96MHz mode: increased by 1mA

■ Serial programming interface: Note about handshaking pins improved

■ specified AD converter channel offset to 4LSB

■ package code of MB96V300 corrected in ordering information

■ Added voltage condition to pull-up resistance spec

■ Lineup: Term “Data Flash” replaced by “independent 32KB Flash”

■ Ordering information: column “Independent 32KB Data Flash” replaced by new column

“Flash/ROM”, column “Remarks” removed

■ Official package dimension drawing with additional notes added

■ Empty pages removed

■ Alarm comparator: Power supply current max values increased, comparison time reduced, mode

transition time and power-up stabilization time newly added

■ Handling devices: Notes added about Serial communication and about using ceramic resonators.

■ Feature list and AC Characteristics: 16MHz maximum frequency is valid for crystal oscillators. For

resonators, maximum frequency depends on Q-factor

■ AC characteristics: PLL phase skew spec added, CLKVCO min=64MHz

■ VOL3 spec improved: spec valid for 3mA load for full Vcc range

■ MB96F345 added

■ Preliminary DC spec of MB96345/346 added

■ Permitted power dissipation of Flash devices in QFP package improved

■ C-Pin cap spec updated: 4.7uF-10uF capacitor with tolerance permitted

■ “Preliminary” watermark removed

To be

released

■ I/O map: IOABK0-5 added at address 000A00H-000A05H

■ Ordering Information: Suffix “A” added to all MB96F345 device versions

■ AD converter IAIN spec improved: 1uA valid up to 105deg, 1.2uA above 105deg

Revision

Date

Modification
